Brush for snow removal

Machine Description

This brush removes 100% of snow, revealing the surface of roads, sidewalks, bike paths and squares.



Technical data
TYPE		 Side sweeper
OCN-600/1200 OCN-600/1500 OCN-600/1800 OCN-600/2100 OCN-600/2400
Brush shaft width 1200 mm 1500 mm 1800 mm 2100 mm 2400 mm
Brush shaft diameter 600 mm 600 mm 600 mm 600 mm 600 mm
Brush roller speed 150 ÷ 450 rpm
Function control Remote - from the lift truck cabin
Brush lifting and lowering Hydraulic
Brush angle in relation to the lift truck Manual (hydraulic, optional) Hydraulic
Drive Hydraulic
Power supply From the lift truck hydraulic system or other source
Min. oil demand* 18 l/min 18 l/min 18 l/min 20 l/min 20 l/min
Max. oil pressure * 150 bar 150 bar 150 bar 150 bar 150 bar
Gauge wheels - - - - Pneumatic 2 pcs.
Sprinkling Gravity or pressure - optional
Dimensions (L x W x H) 1000 x 1400 x 750 [mm] 1000 x 1700 x 750 [mm] 1000 x 2000 x 750 [mm] 1000 x 2300 x 750 [mm] 1325 x 2630 x 1150 [mm]
Road sweeper weight without mount bracket 165 kg 178 kg 190 kg 205 kg 290 kg
